Code Name

 Pleasant Star

Essentials

Capacity

512 GB

Status

Launched

Launch Date

Q3'16

Performance

Sequential Read (up to)

1775  MB/s

Sequential Write (up to)

560  MB/s

Random Read (8GB Span) (up to)

128500  IOPS

Random Write (8GB Span) (up to)

128000  IOPS

Power - Active

100mW (Typical)

Power - Idle

40mW (Typical)

Reliability

Vibration - Operating

2.17 GRMS (5-700Hz) Max

Vibration - Non-Operating

3.13 GRMS (5-800Hz) Max

Operating Temperature Range

0°C to 70°C

Endurance Rating (Lifetime Writes)

288 TBW

Mean Time Between Failures (MTBF)

1.6 million hours

Uncorrectable Bit Error Rate (UBER)

Package Specifications

Form Factor

M.2 22 x 80mm

Interface

PCIe NVMe 3.0 x4

Advanced Technologies

Enhanced Power Loss Data Protection

No

Hardware Encryption

AES 256 bit

–High Endurance Technology (HET)

No

Temperature Monitoring and Logging

No

End-to-End Data Protection

No

Intel® Smart Response Technology

Yes

Intel® Rapid Start Technology

Yes

Intel® Remote Secure Erase

No
