Code Name

 Harris Harbor

Essentials

Capacity

2.048 TB

Lithography Type

3D2 TLC

Performance

Sequential Read (up to)

3230  MB/s

Sequential Write (up to)

1625  MB/s

Random Read (8GB Span) (up to)

340000  IOPS

Random Write (8GB Span) (up to)

275000  IOPS

Power - Active

50 mW

Power - Idle

25 mW

Reliability

Vibration - Operating

2.17 GRMS

Vibration - Non-Operating

3.13 GRMS

Shock (Operating and Non-Operating)

1000 G

Operating Temperature Range

0°C to 70°C

Endurance Rating (Lifetime Writes)

576 TBW

Mean Time Between Failures (MTBF)

1.6 million hours

Uncorrectable Bit Error Rate (UBER)

<1 sector per 10^15 bits read

Package Specifications

Weight

<10 grams

Form Factor

M.2 22 x 80mm

Interface

PCIe NVMe 3.1 x4

Advanced Technologies

Enhanced Power Loss Data Protection

No

Hardware Encryption

AES 256 bit

–High Endurance Technology (HET)

No

Temperature Monitoring and Logging

No

End-to-End Data Protection

Yes

Intel® Smart Response Technology

Yes

Intel® Rapid Start Technology

Yes

Intel® Remote Secure Erase

No
