Code Name

 Postville Refresh

Essentials

Capacity

120 GB

Status

Discontinued

Launch Date

Q1'11

Lithography Type

25 nm

Recommended Customer Price

N/A

Performance

Sequential Read (up to)

270  MB/s

Sequential Write (up to)

130  MB/s

Random Read (8GB Span) (up to)

38000  IOPS

Random Read (100% Span)

38000  IOPS

Random Write (8GB Span) (up to)

14000  IOPS

Random Write (100% Span)

400  IOPS

Latency - Read

75  µs

Latency - Write

90  µs

Power - Active

150 mw (MobileMark 2007 Workload), 3.0 W (64K Sequential Write)

Power - Idle

100 mw (DIPM), .7 W (Non-DIPM)

Reliability

Vibration - Operating

2.17 GRMS (5-700 Hz)

Vibration - Non-Operating

3.13 GRMS (5-800 Hz)

Shock (Operating and Non-Operating)

1,500 G/.5 msec

Operating Temperature Range

0°C to 70°C

Mean Time Between Failures (MTBF)

1,200,000 Hours

Uncorrectable Bit Error Rate (UBER)

1 sector per 1016

Package Specifications

Components

Intel NAND Flash Memory Multi-Level Cell (MLC) Technology

Weight

up to 88 ± 2 grams

Form Factor

2.5" 7mm

Interface

SATA 3.0 3Gb/S

Advanced Technologies

Enhanced Power Loss Data Protection

Yes
