Code Name

 Liberty Harbor

Essentials

Capacity

1.024 TB

Lithography Type

3D2 TLC

Performance

Sequential Read (up to)

550  MB/s

Sequential Write (up to)

500  MB/s

Random Read (8GB Span) (up to)

75000  IOPS

Random Write (8GB Span) (up to)

85000  IOPS

Latency - Read

50  µs

Latency - Write

60  µs

Power - Active

4.5W

Power - Idle

50mW

Reliability

Vibration - Operating

2.17 GRMS  (5-700Hz)

Vibration - Non-Operating

3.13 GRMS (5-800Hz)

Shock (Operating and Non-Operating)

1500 G(Max) at 0.5 msec

Operating Temperature Range

0°C to 70°C

Endurance Rating (Lifetime Writes)

576 TBW

Mean Time Between Failures (MTBF)

1.6 Million Hours

Uncorrectable Bit Error Rate (UBER)

Package Specifications

Weight

up to 45 grams

Form Factor

2.5" 7mm

Interface

SATA 3.0 6Gb/S

Advanced Technologies

Enhanced Power Loss Data Protection

No

Hardware Encryption

AES 256 bit

–High Endurance Technology (HET)

No

Temperature Monitoring and Logging

No

End-to-End Data Protection

Yes

Intel® Smart Response Technology

Yes

Intel® Rapid Start Technology

Yes

Intel® Remote Secure Erase

No
