Feature

Technical Specifications

Processor

Up to two 3rd Generation Intel Xeon Scalable processors, with up to 40 cores per processor

Memory

• 32 DDR4 DIMM slots, supports RDIMM 2 TB max or LRDIMM 4 TB max, speeds up to 3200 MT/s
• Up to 16 Intel Persistent Memory 200 series (BPS) slots, 8 TB max
• Supports registered ECC DDR4 DIMMs only

Storage controllers

• Internal controllers: PERC H745, HBA355I, S150, H355, H345, H755, H755N
• Boot Optimized Storage Subsystem (BOSS-S1): HW RAID 2 x M.2 SSDs 240 GB or 480 GB
• Boot Optimized Storage Subsystem (BOSS-S2): HW RAID 2 x M.2 SSDs 240 GB or 480 GB
• External PERC (RAID): PERC H840, HBA355E

Drive Bays

Front bays:

• Up to 10 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 153 TB
• Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) max 64 TB
• Up to 8 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 122.8 TB Rear bays:
• Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 30.7 TB

Power Supplies

• 800 W Platinum AC/240 Mixed Mode
• 1100 W Titanium AC/240 Mixed Mode
• 1400 W Platinum AC/240 Mixed Mode
• 1100 W DC -48 - 60 V

Cooling options

Air cooling, optional processor liquid cooling

Fans

• Standard fan/High performance SLVR fan/High performance GOLD fan
• Up to four sets (dual fan module) hot plug fans

Dimensions

• Height – 42.8 mm (1.7 inches)
• Width – 482 mm (18.97 inches)
• Depth – 809 mm (31.85 inches) – without bezel

822.84 mm (32.39 inches) – with bezel

Form Factor

1U rack server

Embedded Management

• iDRAC9
• iDRAC Service Module
• iDRAC Direct
• Quick Sync 2 wireless module

Bezel

Optional LCD bezel or security bezel

OpenManage Software

• OpenManage Enterprise
• OpenManage Power Manager plugin
• OpenManage SupportAssist plugin
• OpenManage Update Manager plugin

Mobility

OpenManage Mobile

Integrations and Connections

OpenManage Integrations

• BMC Truesight
• Microsoft System Center
• Red Hat Ansible Modules
• VMware vCenter and vRealize Operations Manager

OpenManage Connections

• IBM Tivoli Netcool/OMNIbus
• IBM Tivoli Network Manager IP Edition
• Micro Focus Operations Manager
• Nagios Core
• Nagios XI

Security

• Cryptographically signed firmware
• Secure Boot
• Secure Erase
• Silicon Root of Trust
• System Lockdown (requires iDRAC9 Enterprise or Datacenter)
• TPM 1.2/2.0 FIPS, CC-TCG certified, TCM 2.0 optional

Embedded NIC

2 x 1 GbE LOM

Network Options

1 x OCP 3.0 (x8 PCIe lanes)

GPU Options

Up to three 75 W single-width GPU

Ports

Front Ports

• 1 x Dedicated iDRAC Direct micro-USB
• 1 x USB 2.0
• 1 x VGA

Rear Ports

• 1 x USB 2.0
• 1 x Serial (optional)
• 1 x USB 3.0
• 2 x RJ-45
• 1 x VGA (optional for liquid cooling configuration)

Internal Ports

• 1 x USB 3.0

PCIe

Up to 3 x PCIe Gen4 low profile slots (all x16 except one x8 slot with SNAP I/O modules) or 2 x PCIe (Gen4) full height slots

Operating System and Hypervisors

• Canonical Ubuntu Server LTS
• Citrix Hypervisor
• Microsoft Windows Server with Hyper-V
• Red Hat Enterprise Linux
• SUSE Linux Enterprise Server
• VMware ESXi

For specifications and interoperability details, see Dell.com.

OEM-ready version available

From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you. For more information, visit Dell.com.
