Code Name

 Lyndonville

Essentials

Capacity

100 GB

Status

Discontinued

Launch Date

Q3'11

Lithography Type

25 nm

Recommended Customer Price

N/A

Performance

Sequential Read (up to)

270  MB/s

Sequential Write (up to)

170  MB/s

Random Read (100% Span)

38500  IOPS

Random Write (100% Span)

2300  IOPS

Latency - Read

75  µs

Latency - Write

85  µs

Power - Active

2.9 W (64K Sequential Write)

Power - Idle

700 mW (Non-DIPM)

Reliability

Vibration - Operating

2.17 GRMS (5-700 Hz)

Vibration - Non-Operating

3.13 GRMS (5-800 Hz)

Shock (Operating and Non-Operating)

1,500 G/.5 msec

Operating Temperature Range

0°C to 70°C

Mean Time Between Failures (MTBF)

2,000,000 Hours

Uncorrectable Bit Error Rate (UBER)

1 sector per 1016

Package Specifications

Components

Intel NAND Flash Memory Multi-Level Cell (MLC) Technology

Weight

up to 80 ± 2 grams

Form Factor

2.5" 7mm

Interface

SATA 3.0 3Gb/S

Advanced Technologies

Enhanced Power Loss Data Protection

Yes

Hardware Encryption

AES 128 bit

–High Endurance Technology (HET)

Yes

Temperature Monitoring and Logging

Yes

End-to-End Data Protection

No
