Essentials

Capacity

4 TB

Status

Launched

Launch Date

Q1'18

Lithography Type

64-Layer 3D TLC NAND

Recommended Customer Price

N/A

Performance

Sequential Read (up to)

3000  MB/s

Sequential Write (up to)

2900  MB/s

Random Read (100% Span)

625500  IOPS

Random Write (100% Span)

113500  IOPS

Latency - Read

77  µs

Latency - Write

18  µs

Power - Active

14

Power - Idle

5

Reliability

Vibration - Operating

2.17 GRMS (5-700 Hz)

Vibration - Non-Operating

3.13 GRMS (5-800 Hz)

Shock (Operating and Non-Operating)

1000G (0.5ms)

Operating Temperature Range

0°C to 70°C

Endurance Rating (Lifetime Writes)

6.3 PBW

Mean Time Between Failures (MTBF)

2 million hours

Uncorrectable Bit Error Rate (UBER)

1 sector per 10^-17 bits read

Package Specifications

Weight

139g

Form Factor

2.5" 15mm

Interface

PCIe NVMe 3.1 x4

Advanced Technologies

Enhanced Power Loss Data Protection

Yes

Hardware Encryption

AES 256 bit

Temperature Monitoring and Logging

Yes

End-to-End Data Protection

Yes
