Code Name

 Liberty Harbor

Essentials

Capacity

256 GB

Lithography Type

3D2 TLC

Performance

Sequential Read (up to)

550  MB/s

Sequential Write (up to)

500  MB/s

Random Read (8GB Span) (up to)

75000  IOPS

Random Write (8GB Span) (up to)

85000  IOPS

Latency - Read

50  µs

Latency - Write

60  µs

Power - Active

4.5W

Power - Idle

40mW

Reliability

Shock (Operating and Non-Operating)

1500 G (Max) at 0.5 msec

Operating Temperature Range

0°C to 70°C

Endurance Rating (Lifetime Writes)

144 TBW

Mean Time Between Failures (MTBF)

1.6 Million Hours

Uncorrectable Bit Error Rate (UBER)

<1 sector per 10^15 bit read

Package Specifications

Weight

6 grams

Form Factor

M.2 22 x 80mm

Interface

SATA 3.0 6Gb/S

Advanced Technologies

Enhanced Power Loss Data Protection

No

Hardware Encryption

AES 256 bit

–High Endurance Technology (HET)

No

Temperature Monitoring and Logging

No

End-to-End Data Protection

Yes

Intel® Smart Response Technology

Yes

Intel® Rapid Start Technology

Yes

Intel® Remote Secure Erase

No
