Code Name

 Jackson Ridge

Essentials

Capacity

240 GB

Lithography Type

20nm

Recommended Customer Price

N/A

Performance

Sequential Read (up to)

550  MB/s

Sequential Write (up to)

270  MB/s

Random Read (8GB Span) (up to)

86000  IOPS

Random Write (8GB Span) (up to)

56000  IOPS

Latency - Read

50  µs

Latency - Write

60  µs

Power - Active

3.8W

Power - Idle

1.5W

Reliability

Vibration - Operating

2.17 GRMS (5-700 Hz) Max

Vibration - Non-Operating

3.13 GRMS (5-800 Hz) Max

Shock (Operating and Non-Operating)

1,000 G (Max) at 0.5 msec

Operating Temperature Range

0°C to 70°C

Endurance Rating (Lifetime Writes)

50GB Writes/Day

Mean Time Between Failures (MTBF)

2,000,000 Hours

Uncorrectable Bit Error Rate (UBER)

<1 sector per 10^17 bits read

Package Specifications

Weight

72 grams ± 2 grams

Form Factor

2.5" 7mm

Interface

SATA 3.0 6Gb/S

Advanced Technologies

Enhanced Power Loss Data Protection

No

Hardware Encryption

AES 256 bit

–High Endurance Technology (HET)

No

Temperature Monitoring and Logging

Yes

End-to-End Data Protection

No
