Essentials

Capacity

240 GB

Status

Launched

Launch Date

Q1'17

Lithography Type

16nm 3D NAND

Recommended Customer Price

N/A

Performance

Sequential Read (up to)

295  MB/s

Sequential Write (up to)

250  MB/s

Random Read (100% Span)

51000  IOPS

Random Write (100% Span)

12500  IOPS

Latency - Read

42  µs

Latency - Write

44  µs

Power - Active

2.6 W

Power - Idle

600 mW

Reliability

Vibration - Operating

2.17 GRMS (5-700 Hz)

Vibration - Non-Operating

3.13 GRMS (5-800 Hz)

Shock (Operating and Non-Operating)

1000G/0.5ms

Operating Temperature Range

0°C to 70°C

Endurance Rating (Lifetime Writes)

599 TBW

Mean Time Between Failures (MTBF)

 2 Million hours

Uncorrectable Bit Error Rate (UBER)

1 sector per 10^17 bits read

Package Specifications

Weight

9 grams +/- 1 gram

Form Factor

M.2 22 x 80mm

Interface

SATA 3.0 6Gb/S

Advanced Technologies

Enhanced Power Loss Data Protection

Yes

Hardware Encryption

AES 256 bit

–High Endurance Technology (HET)

No

Temperature Monitoring and Logging

Yes

End-to-End Data Protection

Yes

Intel® Smart Response Technology

No

Intel® Rapid Start Technology

No
