Code Name

 Hawley Creek

Essentials

Capacity

20 GB

Status

Discontinued

Launch Date

Q1'12

Lithography Type

25 nm

Recommended Customer Price

N/A

Performance

Sequential Read (up to)

220  MB/s

Sequential Write (up to)

100  MB/s

Random Read (8GB Span) (up to)

36000  IOPS

Random Write (8GB Span) (up to)

3300  IOPS

Latency - Read

72  µs

Latency - Write

90  µs

Power - Active

150 mW

Power - Idle

100 mW

Reliability

Vibration - Operating

2.17 GRMS (5-700 Hz)

Vibration - Non-Operating

3.13 GRMS (5-800 Hz)

Shock (Operating and Non-Operating)

1,500 G/.5 msec

Operating Temperature Range

0°C to 70°C

Mean Time Between Failures (MTBF)

1,200,000 Hours

Uncorrectable Bit Error Rate (UBER)

1 sector per 10^16

Package Specifications

Components

Intel NAND Flash Memory Single-Level Cell (SLC) Technology

Weight

< 10 grams

Form Factor

mSATA

Interface

SATA 3.0 3Gb/S

Advanced Technologies

Enhanced Power Loss Data Protection

No

Hardware Encryption

AES 128 bit

–High Endurance Technology (HET)

No

Temperature Monitoring and Logging

No
