Code Name

 Carmel Ridge

Essentials

Capacity

1.2 TB

Status

Launched

Launch Date

Q2'15

Lithography Type

20nm

Performance

Sequential Read (up to)

2400  MB/s

Sequential Write (up to)

1200  MB/s

Random Read (8GB Span) (up to)

440000  IOPS

Random Write (8GB Span) (up to)

290000  IOPS

Latency - Read

20  µs

Latency - Write

20  µs

Power - Active

22

Power - Idle

4

Reliability

Vibration - Operating

2.17

Vibration - Non-Operating

3.13

Shock (Operating and Non-Operating)

1000

Operating Temperature Range

0°C to 70°C

Endurance Rating (Lifetime Writes)

70GB per day

Mean Time Between Failures (MTBF)

1.2M hours

Uncorrectable Bit Error Rate (UBER)

< 1 sector per 10^16 bits read

Package Specifications

Weight

125g

Form Factor

2.5" 15mm

Interface

PCIe NVMe 3.0 x4

Advanced Technologies

Enhanced Power Loss Data Protection

Yes

–High Endurance Technology (HET)

No

Temperature Monitoring and Logging

Yes

End-to-End Data Protection

No

Intel® Smart Response Technology

No

Intel® Rapid Start Technology

No
