3D Graphics Architecture

• Scalable geometry architecture
• Hardware tessellation engine
• NVIDIA^® GigaThread™ engine with dual copy engines
• OpenGL 4.1, DirectX 11.0 and Shader Model 5.0
• Optimized compiler for Cg and Microsoft HLSL
• Up to 16K x16K texture and render processing
• Transparent multisampling and super sampling
• 16x angle independent anisotropic filtering
• 128-bit floating point performance
• 32-bit per-component floating point texture filtering and blending
• 64x full scene antialiasing (FSAA)
• Decode acceleration for MPEG-2, MPEG-4 Part 2 Advanced Simple Profile, H.264, MVC, VC1, DivX (version 3.11 and later), and Flash (10.1 and later)
• DivX (version 3.11 and later), and Flash (10.1 and later)
• Blu-ray dual-stream hardware acceleration (supporting HD picture-in-picture playback)

NVIDIA CUDA Parallel Processing Architecture

• API support includes CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and Fortran
• NVIDIA^® Parallel DataCache™ hierarchy (configurable L1 and unified L2 caches)
• 64 KB of RAM (configurable partitioning of shared memory and L1 cache)
• Fully IEEE 754-2008 compliant fast 32- and 64-bit double precision floating point computation
• Dual Warp Scheduler (schedules and dispatches simultaneously instructions from two independent warps)

Advanced Display Features

• 30-bit color (10-bit per each red, green, blue channel)
• Support for any combination of two connected displays
• DisplayPort resolution up to 2560 x 1600 at 60Hz or 1920 x 1200 at 120Hz
• DisplayPort 1.1a with HDCP support
• DVI-DL output up to 2560 x 1600 at 60Hz or 1920 x 1200 at 120Hz
• DisplayPort to VGA adapter sold separately, PNY PN 91007808-T
• DisplayPort to DVI-DL adapter sold separately, PNY PN 91008126
• DisplayPort to HDMI adapters available from 3rd parties
• Full OpenGL quad buffered stereo support
• NVIDIA^® 3D Vision™ Pro support via USB
• Underscan/overscan compensation and hardware scaling
• NVIDIA^® Mosaic™ multi-display technology
• NVIDIA^® nView^® multi-display technology

DisplayPort and HDMI Digital Audio

• Support for Dolby Digital (AC3), DTS 5.1, Multi-channel (7.1) LPCM, Dolby Digital Plus (DD+), and MPEG-2/MPEG-4 AAC
• Data rates of 44.1 KHz, 48 KHz, 88.2 KHz, 96 KHz, 176 KHz, and 192 KHz
• Word sizes of 16-bit, 20-bit, and 24-bit
• HDMI digital audio requires the purchase of a 3rd party DisplayPort to HDMI adapter
