Feature

Technical Specifications

Processor

Up to two 4th Generation Intel Xeon Scalable processors, with up to 32 cores.

Memory

• 16 DDR5 DIMM slots, supports RDIMM 1 TB max, speeds up to 4800 MT/s
• Supports registered ECC DDR5 DIMMs only

Storage controllers

• Internal Controllers (RAID): PERC H965i, PERC H755, PERC H755N, PERC H355, HBA355i
• Internal Boot: Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 1, 2 x M.2 NVMe SSDs (cold swap), or USB
• External HBAs (non-RAID): HBA355e
• Software RAID: S160

Drive Bays

Front bays:

• Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) max 80 TB
• Up to 8 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 122.88 TB
• Up to 10 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 153.6 TB

Rear bays:

• Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 30.72 TB

Power Supplies

• 1800W Titanium 200—240 VAC or 240 HVDC, hot swap with full redundant
• 1400W Platinum 100—240 VAC or 240 HVDC, hot swap with full redundant
• 1100W Titanium 100—240 VAC or 240 HVDC, hot swap with full redundant
• 1100W LVDC -48 — -60 VDC, hot swap with full redundancy
• 800W Platinum 100—240 VAC or 240 HVDC, hot swap with full redundant
• 700 W Titanium 200—240 VAC or 240 HVDC, hot swap with full redundant
• 600 W Platinum 100—240 VAC or 240 HVDC, hot swap redundant

Fans

• Standard (STD) fans, High performance SLVR fans or High performance GOLD fans
• Up to 7 hot plug fans

Dimensions

• Height – 42.8 mm (1.68 inches)
• Width – 482 mm (18.97 inches)
• Depth – 748.79 mm (29.85 inches) with bezel
• Depth – 712.95 mm (28.05 inches) without bezel
• Weight – 19.45 Kg (55.33 pound)

Form Factor

1U rack server

Embedded Management

• iDRAC9
• iDRAC Direct
• iDRAC RESTful API with Redfish
• iDRAC Service Module
• Quick Sync 2 wireless module

Bezel

Optional LCD bezel or security bezell

OpenManage Software

• OpenManage Enterprise
• OpenManage Power Manager plugin
• OpenManage Service plugin
• OpenManage Update Manager plugin
• CloudIQ for PowerEdge plug in
• OpenManage Enterprise Integration for VMware vCenter
• OpenManage Integration for Microsoft System Center
• OpenManage Integration with Windows Admin Center

Mobility

OpenManage Mobile

OpenManage Integrations

• BMC Truesight
• Microsoft System Center
• OpenManage Integration with ServiceNow
• Red Hat Ansible Modules
• Terraform Providers
• VMware vCenter and vRealize Operations Manager

Security

• Cryptographically signed firmware
• Data at Rest Encryption (SEDs with local or external key mgmt)
• Secure Boot
• Secure Erase
• Secured Component Verification (Hardware integrity check)
• Silicon Root of Trust
• System Lockdown (requires iDRAC9 Enterprise or Datacenter)
• TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ

Embedded NIC

2 x 1 GbE LOM card

Network options

1 x OCP card 3.0 (optional)

Note: The system allows either LOM card or an OCP card or both to be installed in the system.

GPU Options

None

Ports

Front Ports

• 1 x iDRAC Direct (Micro-AB USB) port
• 1 x USB 2.0
• 1 x VGA

Rear Ports

• 1 x Dedicated iDRAC Ethernet port
• 1 x USB 2.0
• 1 x USB 3.0
• 1 x VGA
• 1 x Serial (optional)

Internal Ports

• 1 x USB 3.0 (optional)

PCIe

• 1 CPU Configuration: Up to 2 PCIe slots (1 x16 Gen4 + 1 x8 Gen5)

• 2 CPU configuration: Up to 3 PCIe Gen4 slots (1 x16 Gen4 + 2 x8 Gen4) or up to 2 PCIe Gen5 slots (1 x16 Gen5 + 1 x8 Gen5)

Operating System and Hypervisors

• Canonical Ubuntu Server LTS
• Microsoft Windows Server with Hyper-V
• Red Hat Enterprise Linux
• SUSE Linux Enterprise Server
• VMware ESXi

For specifications and interoperability details, see Dell.com/OSsupport.

OEM-ready version available

From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you. For more information, visit Dell.com -> Solutions -> OEM Solutions.
