Essentials

Product Collection

Intel® Xeon® 6 processors

Code Name

Products formerly Raptor Lake

Vertical Segment

Server

Processor Number

6357P

Lithography

Intel 7

Recommended Customer Price

CPU Specifications

Total Cores

8

# of Performance-cores

8

Total Threads

16

Max Turbo Frequency

5.4 GHz

Intel® Turbo Boost Max Technology 3.0 Frequency ‡

5.1 GHz

Intel® Turbo Boost Technology 2.0 Frequency‡

5.4 GHz

Processor Base Frequency

3 GHz

Cache

24 MB

Bus Speed

16 GT/s

TDP

80 W

Supplemental Information

Marketing Status

Launched

Launch Date

Q1'25

Servicing Status

Baseline Servicing

Embedded Options Available

No

Use Conditions

Server/Enterprise

Memory Specifications

Max Memory Size (dependent on memory type)

128 GB

Memory Types

DDR5-4800

Maximum Memory Speed

4800 MT/s

Max # of Memory Channels

2

Intel® Optane™ Persistent Memory Supported

No

ECC Memory Supported   ‡

Yes

Expansion Options

Max # of DMI Lanes

8

Scalability

1S Only

PCI Express Revision

5.0

Microprocessor PCIe Revision

Gen 5

PCI Express Configurations ‡

Up to 1x16+1x4 |  2x8+1x4

Max # of PCI Express Lanes

20

Package Specifications

Sockets Supported

FCLGA1700

Max CPU Configuration

1

TJUNCTION

100°C

Advanced Technologies

Intel® Turbo Boost Max Technology 3.0 ‡

Yes

Intel® Turbo Boost Technology ‡

2.0

Intel® Hyper-Threading Technology ‡

Yes

Intel® Transactional Synchronization Extensions

No

Intel® 64 ‡

Yes

Instruction Set

64-bit

Instruction Set Extensions

Intel® SSE4.1 |  Intel® SSE4.2 |  Intel® AVX2

Idle States

Yes

Enhanced Intel SpeedStep® Technology

Yes

Thermal Monitoring Technologies

Yes

Security & Reliability

Intel® Total Memory Encryption - Multi Key

Yes

Intel® Total Memory Encryption

Yes

Intel® AES New Instructions

Yes

Secure Key

Yes

Intel® OS Guard

Yes

Intel® Trusted Execution Technology ‡

Yes

Execute Disable Bit ‡

Yes

Intel® Boot Guard

Yes

Mode-based Execute Control (MBEC)

Yes

Intel® Virtualization Technology with Redirect Protection (VT-rp) ‡

Yes

Intel® Virtualization Technology (VT-x) ‡

Yes

Intel® Virtualization Technology for Directed I/O (VT-d) ‡

Yes

Intel® VT-x with Extended Page Tables (EPT) ‡

Yes
