General Specifications |
Network Processor | Broadcom NetXtreme BCM5720 chipset |
| Data Rate | Two ports, each at 1 Gbps full duplex (2 Gbps aggregate per port); 4 Gbps aggregate full duplex theoretical bandwidth. | |
| Data Path | One lane (x1) PCI Express compatible with x1, x4, x8, and x16 PCI Express slots | |
| Bus Type | PCIe 2.0 | |
| Bus Speed | Gen 2.0 x1 | |
| Interrupt Levels | Automatically configured | |
| Connector | RJ-45 (Two) | |
| Cable Distance | Up to 328 ft (100 m) | |
| Wiring | Category 5/ (CAT-5) or better twisted-pair cabling | |
| Dimensions | 11.18 cm x 5.59 cm [4.4 in x 2.2 in (L x W)] (without bracket) | |
| Form Factor | Low profile card with both full height (pre-installed) and half height brackets included in kit | |
| IEEE Compliance | 802.3,802.3u,802.3ab,802.3x,802.3ad,802.1p, 802.1q, 802.3az, 1588, 802.1as | |
| Power and Environmental Specifications | Operating | Temperature | 32° to 131° F (0° to 55° C) |
| Humidity | 10% to 90% non-condensing | ||
| Power | 2.2 W (1000Base-T, both ports, maximum traffic) 2.1 W (1000Base-T, both ports, idle, without EEE link partner) 1.7 W (1000Base-T, both ports, idle, EEE link partner) 0.6 W (AUX power with WoL) |
||
| Emissions | Class B | ||
| Agency approvals | USA | FCC Part 15 Class B | |
| Canada | ICES=--3, Issue 4 | ||
| Japan | VCCI V3 (2010.04) Class B | ||
| Korea | KN22 ClassB, KN24 | ||
| Australia | EN55022:2006+A12007 class B | ||
| European Union | EN55024:1998+A1:2011+A2; EN61000-3- 2:2006, EN61000-3-3:2008 | ||
| International | EN55022:2006 + A1:2007 Class B | ||
| Safety | 6 of 6 | ||
| Other | UL Mark (USA and Canada) | ||
| CE Mark | |||
| EN 60590 | |||
|
Operating System Support |
Microsoft Windows Server 2008 (32/64), Enterprise, Web, Embedded, and R2 |
| Microsoft Windows HPC Server 2008 | |
| Microsoft certified miniport and teaming drivers | |
| Microsoft Windows 2008 Standard (32 and x64) | |
| Microsoft Windows 2008 Enterprise (32 and x64) | |
| Microsoft Windows Small Business Server 2011 (SBS V7) - base | |
| Microsoft Windows Small Business Server 2011 Essentials | |
| RHEL 5.7 x86 and AMD 64 & EM 64T | |
| RHEL 6.1 x86 and AMD 64 & EM 64T | |
| SLES10 x86 and AMD 64 & EM 64T | |
| SLES 11x86 and AMD 64 & EM64T | |
| Solaris 10 | |
| VMware 4.1u2 and 5.0u1 | |
| Citrix | |
| Hyper-V (Windows 2008 32 and 64) | |
| NOTE: For more Linux OS support & certification information, please visit our the ProLiant & BladeSystem Server Linux matrix:http://h18004.www1.hp.com/products/servers/linux/hplinuxcert.html | |
