Technical Specifications
| Compliance | IEEE | 802.3ae,802.3ad, 802.1p, 802.1Q 802.3x 802.3z | |
| Safety | UL, Canada UL, EN 60950 | ||
| Emissions | FCC Class A, VCCI Class A, BSMI Class A, CISPR 22 Class A, ACA Class A, EN55022 Class A, EN55024-1, ICES-003 Class A, MIC Class A | ||
| Other | PCIe v2.0 RoHS compliance 6 of 6 IPv4, IPv6 CE ACPI 1.1a Microsoft WHQL (Windows Hardware Quality Labs) Server Design Guide version 3.0 (SDG 3.0) | ||
| General Specifications | Controller | NETXEN NX3031 | |
| Onboard memory | 256MB | ||
| Data rate | 10,000 Mbps per port, (40 Gbps aggregate full duplex, dual ports) | ||
| Data Path | 8 Lane (x8) PCI Express, compatible with x4 and x8 bus widths | ||
| Dimensions (LxW) | 6.6 x 2.7 in (16.7 x 6.8 cm) without bracket | ||
| Power and Environmental Specifications | Operating | Temperature | 32° to 131° F (0° to 55° C ) |
| Humidity | 10% to 90% non-condensing | ||
| Non-operating | Temperature | -85° to 185° F (-65° to 85° C) | |
| Humidity | 5% to 95% | ||
| Power | 2.03A @ 12V | ||
| Operating System Support | Microsoft Windows Server 2008, Server 2008R2, and HPC Server 2008, 32 and 64-bit Microsoft Windows Small Business Server 2011 | ||
| Microsoft Windows Server 2008, Server 2008R2, and HPC Server 2008, 32 and 64-bit | |||
| Microsoft Windows Server Hyper-V | |||
| Red Hat Enterprise Linux | |||
| SUSE Linux Enterprise Server | |||
| SLES 9, 10, 11 Solaris 10 | |||
| VMware 3.5, 4.0, 4.1 and 5.0 | |||
| Solaris 10 5/09, 10/09 | |||
| NOTE: For more Linux OS support & certification information, please visit our the ProLiant & BladeSystem Server Linux matrix:http://h18004.www1.hp.com/products/servers/linux/hplinuxcert.html | |||
