SAS 6Gbps Models

Standard

MG03SCA100

Drive Capacity

1TB

Performance

Rotational Speed

7,200 RPM

Average Latency

4.17ms

Sustained transfer rate (Max)

155 MB/s

Buffer Size

64MiB FIFO ring buffer

Power Requirements

Voltage

5V±5% , 12V±5%

Read/Write Power

11.3 watts

Low Power Idle

6.0 watts

Physical Size

Dimensions (W)x(D)x(H)

101.6 mm x 147 mm x 26.1 mm

Weight

720g (Max.)

Environmental

Temp – Operating

5° to 55°C (41° to 131°F)

Temp - Non-Operating

-40° to 70°C

Vibration - Operating

7.35 m/s² (0.75G, 5 to 300Hz)

2.45 m/s² (0.25G, 300 to 500Hz)

Vibration - Non-Operating

49 m/s² (5G, 5 to 500Hz)

Shock - Operating

686 m/s² (70G) 2ms

Shock - Non-Operating

2,940 m/s² (300G) 2ms

Acoustics

Acoustics (idle)

31 dB

Reliability

MTTF

1,200,000 hours

Load/Unload

600,000 times

Operation Condition

24 hours/day, 7day/week, 100% duty
