    • IBM x3650 M4 PCIX Riser Card (2 PCIX + 1 x16 PCIe slots)

      [ Part number: 81Y6895; 81Y6843 ]

      IBM x3650 M4 PCIX Riser Card 2 (1 x16 FH/HL PCIe + 2 PCIX FH/FL Slots)

      Giá: Liên hệ

    Chọn mua

    Mua hàng





    The server supports up to six PCIe slots with different riser cards installed into two riser sockets on the system planar (one riser socket supports installation of one riser card). Riser 1 supplies slots 1, 2, and 3. Riser 2 supplies slots 4, 5, and 6. Standard models have Riser card 1 installed with three PCIe 3.0 x8 slots. To enable slots 4 - 6, install a second processor and a second riser card.

    The following table lists the PCI riser card options available.

    Table 13. PCI riser card options

    Part number Feature
    code
    Description Maximum
    supported
    69Y5321 A1JU x3650 M4 PCIe Riser Card (3 x8 PCIe slots)
    (one included in standard models in Riser socket 1)
    2
    69Y5322 A1JQ x3650 M4 PCIe Riser Card (1 x16 + 1 x8 PCIe slots) 2
    81Y6843 A1JS x3650 M4 PCIX Riser Card (2 PCIX + 1 x16 PCIe slots) 2
    90Y5085 A3A1 x3650 M4 PCIe Riser Card 2 (1 x16 for GPU + 1 x8 FH/HL Slots) 2


    The slot form factors are as follows:


    • Slot 1: PCIe x8, PCIe x16, or PCI-X; full-height, full-length
    • Slot 2: PCIe x8 or PCI-X; full-height, half-length (not present if Riser 1 contains 90Y5085 riser card)
    • Slot 3: PCIe x8 or PCIe x16; full-height, half-length (not present if Riser 1 contains 69Y5322 riser card)
    • Slot 4: PCIe x8, PCIe x16, or PCI-X; full-height, full-length
    • Slot 5: PCIe x8 or PCI-X; full-height, full-length (not present if Riser 2 contains 90Y5085 riser card)
    • Slot 6: PCIe x8 or PCIe x16; full-height, half-length (not present if Riser 2 contains 69Y5322 riser card)


    The slots are shown in the following figure.


    Figure 6. Slot dimensions

    The specific slots that are available depend on the riser cards installed in Riser socket 1 and Riser socket 2, as shown in the following table. Standard models have 69Y5321 installed in Riser socket 1.

    Tip: All slots support full-height adapters. Slots 1, 4, and 5 support full-length adapters, whereas slots 2, 3, and 6 (when present) support half-length adapters.

    Table 14. PCIe slot descriptions (FH=full height, FL=full length, HL=half length, DW=double width)

    Slot
    number
    PCIe 3 x8 riser
    69Y5321 (standard)
    PCIe x16 riser
    69Y5322
    PCI-X riser
    81Y6843
    GPU riser
    90Y5085
    Riser
    socket 1
    (CPU 1)
    1: PCIe 3.0 x8; FH/FL 1: PCIe 3.0 x16 FH/FL 1: PCI-X 64b/133 FH, FL 1: No slot present
    2: PCIe 3.0 x8; FH/HL 2: PCIe 3.0 x8 FH/HL 2: PCI-X 64b/133 FH, HL 2: PCIe 3.0 x16 FH, FL, DW
    3: PCIe 3.0 x8; FH/HL 3: No slot present 3: PCIe 3.0 x16 FH, HL 3: PCIe 3.0 x8 FH, FL
    Riser
    socket 2
    (CPU 2
    required)
    4 :PCIe 3.0 x8 FH/FL 4: PCIe 3.0 x16 FH/FL 4: PCI-X 64b/133 FH, FL 4: No slot present
    5: PCIe 3.0 x8 FH/FL 5: PCIe 3.0 x8 FH/FL 5: PCI-X 64b/133 FH, FL 5: PCIe 3.0 x16 FH, FL, DW
    6: PCIe 3.0 x8 FH/HL 6: No slot present 6: PCIe 3.0 x16 FH, HL 6: PCIe 3.0 x8 FH, HL


    Note: Slots 4, 5, and 6 require a second processor to be installed.
