General Specifications |
Network Processor | Broadcom BCM57810S chipset |
| Data Rate | Two ports, each at 20 Gbps full duplex; 40 Gbps aggregate full duplex theoretical bandwidth. | |
| Onboard Memory | 256MB | |
| Bus Type | PCIe v2.0 (Gen 2) x 8 | |
| Form Factor | Standard and low profile adapter compliant with the PCIe standard | |
| IEEE Compliance | 802.3, 802.3x, 802.2x, 802.3ad, 802.1Qaz, 802.1Qau, 802.1Qbb, 802.1Qbg, 802.1ax | |
| Connector | RJ-45 (Two) | |
| Wiring | CAT6 UTP or better twisted-pair | |
| Cable Distance | Maximum distances for CAT6 cable are 30 meters (98 feet). Maximum distances for CAT6a are 100 meters (328 feet). |
|
|
NOTE: The HP 530T adapter can use existing UTP CAT6 (or better) cable to deliver Gigabit Ethernet over copper, according to the IEEE 802.3an specifications. For new installations, CAT6a cable is recommended. Cabling details:
|
||
| Power and Environmental Specifications | Operating | Temperature | 32° to 131° F (0° to 55° C) |
| Humidity | 5% to 95% non-condensing | ||
| Power | 9W maximum | ||
| Emissions classification | 15.5W typical, 18.2W maximum | ||
| Agency approvals | USA | FCC Part 15 Class A | |
| Canada | ICES=003, Issue 4 | ||
| Japan | VCCI V3 (2010.04) Class A | ||
| International | EN55022:2006 + A1:2007 Class A, EN55024:1998+A1:2011+A2; EN61000-3-2:2006, EN61000-3-3:2008 | ||
| Taiwan | BSMI, CNS13438 (2006) Class A | ||
| Australia/New Zealand (AS/NZS): | EN55022:2006+A12007 class A | ||
| Korea | KN22 Class A, KN24 | ||
| RoHS Compliance | 6 of 6 | ||
| Safety | UL Mark (USA and Canada) | ||
| CE Mark | |||
| EN 60590 | |||
|
Operating System Support |
Microsoft Windows Server 2008 (32/64), Enterprise, Standard, Datacenter, Web, Embedded, Foundation (SP2 and R2 w/SP1) |
| Microsoft Windows HPC Server 2008 (SP2 and R2 w/SP1) | |
| Microsoft Windows Small Business Server 2011 (SBS V7) – Base | |
| Microsoft Windows Small Business Server 2011 Essentials | |
| Microsoft Windows Multipoint Server 2011 | |
| Microsoft Windows Server 2012 | |
| Hyper-V (R2 w/SP1) | |
| RHEL 5.7/5.8/5.9 x86 and AMD 64 & EM 64T | |
| RHEL 6.1/6.2/6.3 x86 and AMD 64 & EM 64T | |
| SLES 10 SP4 x86 and AMD 64 & EM 64T | |
| SLES 11 SP2 x86 and AMD 64 & EM 64T | |
| Solaris 10/11 | |
| VMware vSphere 4.1 and 5.0 | |
| Citrix XenServer 6.0/6.1 | |
| NOTE: For more Linux OS support & certification information, please visit our the ProLiant & BladeSystem Server Linux matrix:http://h18004.www1.hp.com/products/servers/linux/hplinuxcert.html | |
